WiFi-7 Tri-Band Antenna
P/N:OA-6E-BD-02
RF Specification
| Frequency Range |
2400~2500MHz / 5150~5850MHz / 5925~7125 MHz |
| Polarization |
Linear |
| HPBW / Horizontal |
360° |
| HPBW / Vertical |
45° |
| Peak Gain |
1.6 dBi / 3.6 dBi / 3.7 dBi max. |
| Efficiency |
71% / 74% / 72% min. |
| VSWR |
2.0 typ. |
| Power Handing |
2W(cw) |
| Impedance |
50 Ohms |
| Connector |
RP-SMA Plug |
Environmental & Mechanical Characteristics
Temperature: -20℃to +55℃
Humidity: 95% @55℃
Antenna Housing Color: White
Antenna Housing Material: PC
Weight: 17.0g
Dimensions: 119.3 mm(L)x30.8 mm(W) x11.0 mm(OD)
